Technical Specification

Camera

Image Sensor

1/2.8” 2Megapixel progresive CMOS

Effective Pixels

1920(H) x1080(V)

RAM/ROM

64MB/16MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

S/N Ratio

More than 50dB

IR Distance

15 m (49.21 ft) (Warm light)


IR On/Off Control

Auto/ Manual

IR LEDs

1 (Warm light)


Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

2.8 mm


3.6 mm

Max. Aperture

F1.6

Angle of View

H: 107°; V: 56°; D: 127°;H: 88°; V: 44°; D: 105°

Focus Control

Fixed

Close Focus Distance

0.7 m (2.30 ft); 1.3 m (4.26 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

43.9 m (144.0 ft)


17.5 m (57.4 ft)


8.8 m (28.9 ft)


4.4 m (14.4 ft)


3.6 mm

58.9 m (193.24 ft)


23.6 m (71.9 ft)


11.8 m (36.1 ft)


5.9 m (18.0ft)


PTZ

Pan/Tilt Range

Pan:0° ~360° ;Tilt:0° ~78° ;Rotation:0° ~360°

Video

Compression

H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)


Streaming Capability

2 Streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)


Frame Rate

Main stream: 1920 × 1080@1 fps–25/30 fps


Sub stream: 704 × 576@1 fps–25 fps 704 × 480@1 fps–30 fps


*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity


Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32 kbps–6144 kbps


H.265: 12 kbps–6144 kbps

Day/Night

Color/B/W

BLC Mode

BLC / HLC /DWDR

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Smart IR

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio & Alarm

Built-in MIC


Audio Compression

Alarm Event


Yes


G.711A; G.711Mu; G.726

Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception


Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP

Interoperability

ONVIF (Profile S); CGI; P2P; Genetec

Streaming Method

Unicast / Multicast

Max. User Access

6 (Total bandwidth: 36 M)

Edge Storage

FTP

Web Viewer

IE, Chrome, Firefox

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE-LVD: EN 62368-1

CE-EMC: Electromagnetic Compatibility Directive

2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

Interface

Video Interface

N/A

Audio Interface

N/A

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC12V PoE (802.3af)

Power Consumption

Basic power consumption: 1.2 W (12 VDC); 2W (PoE)

Max. power consumption (H.265+Warm light intensity):

4.2 W (12V DC); 5.4W (PoE)


Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Strorage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Construction

Casing

Metal+Plastic

Dimensions

Net Weight

0.24Kg(0.5lb)

Gross Weight

0.37Kg(0.8lb)
